Model
|
AT-S1505CF–5 Port Ethernet Switch
|
| Type | ActiveTro 5-Port Fast Ethernet Switch |
|
Ports & Connectivity
|
5 × 10/100Mbps auto-sensing RJ45 ports with Auto MDI/MDIX |
|
Performance & Speed
|
Store-and-Forward switching, 7.44Mpps forwarding rate, 10Gbps backplane bandwidth, 1M buffer memory, 2K MAC address table with self-learning & updating |
|
Power & Efficiency
|
Low power consumption (Standby 0.7W, Max <2W), 5V/1A external adaptor, AC 100–240V 50/60Hz input |
|
Design & Installation
|
Compact 100 × 70 × 27 mm design; supports desktop, wall mount, or 19-inch 1U rack installation |
|
Operating Conditions
|
Works from -20°C to +55°C with 5–90% humidity; Storage from -40°C to +75°C with 5–95% humidity |
| Durability | Built-in ESD protection (±8kV contact, ±15kV air) and surge protection (±4kV) |
| Reliability |
Stable non-blocking transmission, IEEE 802.3/802.3u/802.3x/802.3ab/802.3z compliant |
